BGP Wall Panels

30.05.19 06:11 PM By Sajjan Kumar

All About Of BGP Wall Panels.

BGP Wall Panels

BGP Wall Panels made from 100% virgin polypropylene material possess all the advantages for polypropylene. Manufactured by sheet extrusion technique and

fabricated by heat lamination.  My Wall Panels offer a range of benefits that make them a great option for room decor. From ample design options to impressive

durability, wall panels provide both aesthetic and functional solutions for your home


Wall Paneling facts:

  • 100% Waterproof
  • Easy to clean, Hygienic
  • Extremely easy to install
  • Aging-resistant, High intensity.
  • Termite Proof, Corrosive-resistant
  • Can be applied directly over existing wall.
  • (no muddling, sanding or painting required.

Water Resistant
BGP Wall Panels are very popular for bathroom and kitchen areas as they are water-repellent and mold resistant, but they can be used all over the house especially in basements, attics, garages and also bed and living rooms.

TECHNICAL DATA
Made from 100% virgin polypropylene material possess all the advantages of polypropylene.
  • Manufactured by sheet extrusion technique and fabricated by heat lamination.
  • Being a fabricated product its physical and mechanical properties can be customized to meet the market needs.
  • Typical Properties of polypropylene are given below :

    Particulars                                          Typical Values                 Test Standard

    Specific Gravity                                                       0.9 to 9.1

    Tensile Strength (ib/inch 2)                                   4000 to 5200                              BS2782

    Elongation at break (%)                                         400 to 900                                 BS2782

    Notch Izod Impact Strength (ft.ib/inch)             2.5 to 4.0                                   BS2782

    Shore Hardness D                                                 71 to 75                                       ASTM.D.148-57

    Vicat Softening point (°C)                                     150                                               BS2782

    Dielectric Constant (106 c/s)                                 2.0 to 2.15                                   ASTM.D.150-54

    Water absorption, 24 hrs, 1/8” thick (%)             0.01-0.03                                     D570

    Hardness, Rockwell R                                           80-110                                           D785

    Thermal conductivity                                           2.8                                                  C177



    Property

    • Humidity Resistance                                99%RH
    • Material Fire Performance                     V2 (also perform V0) rating
    • Light Reflectance                                     80%
    • Material                                                   Virgin Polypropylene




    INSTALLATION GUIDE

    1. Take the size of wall.

    2. Scrape the wall.

    3. Cut the sheet accordingly to size of the wall.

    4. Apply special rubber base adhesive (SG 1000 of 3M / SP5 of Pidilite ) on sheet as well as on wall. Allow it to dry for 5-10 minutes.

    5. Put the sheet on wall and apply pressure from one end to the other gradually, so that no air bubble remains inside.

    6. Kindly note that when you use 2 sheets besides one another maintain a gap of 4mm for sealant to be filled in.

    7. Hammer the sheet by placing a plain wooden plank as shown in figure for fixing.

    8. Put white tape on all borders of the sheet & the wall where the sheet is put up in such a way that silicon is filled in between the portion of both the tapes. This is used as sealant which serves as a frame of the sheet on the wall.

    9. Then remove the tape simultaneously as you fill silicon in the gaps of the tape.

    10. And the fire proof , termite proof, long lasting wall in your favorite design is ready in few hours.






BGP Wall Panels Catalogue

Sajjan Kumar
